Produktblad
Management features
Switch typ
hanterad
Switch-lager
L2
Stöd för garanterad tjänstekvalitet (QoS)
Anslutningar
Konsolport
RJ-45/USB Type-C
Antal installerade SFP+-moduler
2
Typ av grundläggande RJ-45 Ethernet-portar
Gigabit Ethernet (10/100/1000)
Antal grundläggande RJ-45 Ethernet-portar
48
USB C-typ, antal portar
1
Antal USB Typ A-portar
1
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.3at, IEEE 802.3af
Data transmission
Switch kapacitet
720 Gbit/s
Paketbuffertminne
16 MB
Genomströmning
535 Mpps
Design
Staplingsbar
Produktens färg
Svart
Återställningsknapp
Rackmontering
Formfaktor
1U
Prestanda
Flashminne
32000 MB
Minnestyp
DDR4-SDRAM
Processorfrekvens
1800 MHz
Internminne
8000 MB
Processor
ARM Cortex-A72
Inbyggd processor
Fysisk stackning (enheter)
10
Strömtillförsel
Meddelane om effektförbrukning
With single JL086A PSU: Idle: 207W 100% Traffic Rate: 283W With single JL087A PSU: Idle: 208W 100% Traffic Rate: 282W With single JL670A PSU: Idle: 211W 100% Traffic Rate: 283W
AC-inspänning
100 - 240 V
Notering för strömförsörjning
2 field‐replaceable, hot‐swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A and JL670A.
Strömkälla
AC/PoE
Power over Ethernet (PoE)
Antal Power over Ethernet plus (PoE +)-portar
48
Strömförsörjning via Ethernet (PoE) stöd
Power over Ethernet (PoE)-effekt per port
30 W
Total Power over Ethernet (PoE)-budget
2880 W
Övrigt
Externa anslutningar
48x 10/100/1000 BaseT PoE+ ports supporting up to 30W per port 4x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at 1x USB-C console port 1x USB Type-A host port 1x OOBM port [4] 450G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which require QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports.
Fläkt
Switch has two fan tray slots and comes with one fan tray installed. Minimum one fan tray required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Vikt (imperial)
6,02 kg (13.3 lbs)
Minne och processor
Quad Core Arm Cortex A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 16 MB Shared Packet Buffer Memory
Prestandahantering
1 default VRF, 1 management VRF
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Höjd
385 mm
Bredd
44 mm
Djup
442 mm
Vikt
6,02 kg
|
