Produktblad
Management features
Switch-lager
L2
Stöd för garanterad tjänstekvalitet (QoS)
Webbaserad adminstraion
Switch typ
hanterad
Trafikklassificering
Trafikutformning
Anslutningar
Antal USB Typ A-portar
1
Antal hanteringsportar
1 styck
Fiberoptiska kontakten
SFP28, SFP56
Fiberportar kvantitet
4
Typ av grundläggande RJ-45 Ethernet-portar
2.5G Ethernet (100/1000/2500)
Antal grundläggande RJ-45 Ethernet-portar
48
Nätverk
Portspegling
10G stöd
Data transmission
Paketbuffertminne
16 MB
Genomströmning
580 Mpps
Switch kapacitet
780 Gbit/s
Design
Produktens färg
Silver, Svart
Rackmontering
Formfaktor
1U
Staplingsbar
Prestanda
Inbyggd processor
Processorfrekvens
1800 MHz
Internminne
8000 MB
Flashminne
32000 MB
Minnestyp
DDR4-SDRAM
Fysisk stackning (enheter)
10
Strömtillförsel
Meddelane om effektförbrukning
With JL086A PSU: Hibernation (0 rpm fan): 43W Idle: 104W 100% Traffic Rate: 173W With JL087A PSU: Hibernation (0 rpm fan): 41W Idle: 104W 100% Traffic Rate: 173W With JL670A PSU: Hibernation (0 rpm fan): 37W Idle: 115W 100% Traffic Rate: 184W
Strömkälla
AC/DC
Växelström Frekvens
50/60 hz
AC-inspänning
100 - 240 V
Strömförsörjning ingår
Notering för strömförsörjning
2 field‐replaceable, hot‐swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A and JL670A.
Power over Ethernet (PoE)
Total Power over Ethernet (PoE)-budget
2880 W
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Externa anslutningar
48x HPE Smart Rate 100M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port 4x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W) 1x USB-C console port 1x USB Type-A host port 1x OOBM port [4] 450G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which require QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports. [5] 100M use on HPE Smart Rate ports is limited to full‐duplex only. For 100M half‐duplex support, use 1G ports on other models.
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Minne och processor
Quad Core Arm Cortex A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 16 MB Shared Packet Buffer Memory
Prestandahantering
1 default VRF, 1 management VRF
Fläkt
Switch has two fan tray slots and comes with one fan tray installed. Minimum one fan tray required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Vikt (imperial)
6,02 kg (13.3 lbs)
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Vikt
6,02 kg
Bredd
44 mm
Djup
442 mm
|
Tillbehör |
