Produktblad
Management features
Switch-lager
L2
Stöd för garanterad tjänstekvalitet (QoS)
Switch typ
hanterad
Anslutningar
Konsolport
RJ-45/USB Type-C
Typ av grundläggande RJ-45 Ethernet-portar
10G Ethernet (100/1000/10000)
Antal grundläggande RJ-45 Ethernet-portar
24
USB C-typ, antal portar
1
Antal SFP28-ingångar
2
Antal USB Typ A-portar
1
Nätverk
10G stöd
Kommunikationsstandarder
IEEE 802.1af, IEEE 802.3at, IEEE 802.3bt
Data transmission
Switch kapacitet
780 Gbit/s
Paketbuffertminne
16 MB
Genomströmning
580 Mpps
Protokoll
Router-protokoll
BGP, OSPF
Design
Produktens färg
Svart
Rackmontering
Staplingsbar
Prestanda
Inbyggd processor
Fysisk stackning (enheter)
10
Processorfrekvens
1800 MHz
Internminne
8000 MB
Flashminne
32000 MB
Minnestyp
DDR4-SDRAM
Strömtillförsel
Strömkälla
AC/PoE
Notering för strömförsörjning
2 field‐replaceable, hot‐swappable power supply slots 1 minimum power supply required (ordered separately). Supported PSUs JL086A, JL087A and JL670A.
AC-inspänning
100 - 240 V
Strömförsörjning ingår
Meddelane om effektförbrukning
With JL086A PSU: Hibernation (0 rpm fan): 37W Idle: 90W 100% Traffic Rate: 143W With JL087A PSU: Hibernation (0 rpm fan):41W Idle: 90W 100% Traffic Rate: 140W With JL670A PSU: Hibernation (0 rpm fan): 35W Idle: 101W 100% Traffic Rate: 152W
Power over Ethernet (PoE)
Total Power over Ethernet (PoE)-budget
2880 W
Power over Ethernet (PoE)-effekt per port
60 W
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Externa anslutningar
24x HPE Smart Rate 100M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port 4x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W) 1x USB-C console port 1x USB Type-A host port 1x OOBM port [4] 450G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which require QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports. [5] 100M use on HPE Smart Rate ports is limited to full‐duplex only. For 100M half‐duplex support, use 1G ports on other models.
Minne och processor
Quad Core Arm Cortex A72 @ 1.8GHz, 8 GB DDR4, 32 GB eMMC 16 MB Shared Packet Buffer Memory
Prestandahantering
1 default VRF, 1 management VRF
Latens
1 Gbps: 4.24 μs 10 Gbps: 1.50 μs 25 Gbps: 2.91 μs 50 Gbps: 3.49 μs
Fläkt
Switch has two fan tray slots and comes with two fan trays installed. Minimum two fan trays required. Fan trays are field replaceable and hot‐swappable. Each fan tray contains two fans.
Vikt (imperial)
6,02 kg (13.3 lbs)
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Vikt
6,02 kg
Höjd
44 mm
Bredd
44 mm
Djup
442 mm
Logistikdata
Farligt gods, klass
Klass 6
|
