Produktblad
Management features
Switch typ
hanterad
Nätverk
Kommunikationsstandarder
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
10G stöd
Data transmission
Genomströmning
20000 Mpps
Switch kapacitet
14000 Gbit/s
Design
Staplingsbar
Rackmontering
Formfaktor
7U
Prestanda
Flashminne
32000 MB
Minnestyp
DDR4-SDRAM
Processorfrekvens
1800 MHz
Internminne
8000 MB
Processor
ARM Cortex-A72
Inbyggd processor
Strömtillförsel
AC-inspänning
200 - 240 V
Strömförsörjning ingår
Meddelane om effektförbrukning
R0X35A PSU: 1800W at 200–240 VAC, 1100W at 110–127 VAC R0X36A PSU: 3000W at 200–240 VAC, 1500W at 110–127 VAC
Notering för strömförsörjning
Power supply units are not included; order separately. Supports four modular front‐serviceable power supplies with removable rear‐serviceable power cord inlet adapters. Supported power supplies: R0X35A, R0X36A. PoE available will be dependent on the number of management modules, line cards, fan trays and the number of power supplies used. Power supplies not included; order separately.
Strömkälla
AC
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Externa anslutningar
High speed, non-blocking 1/10/25/40/50/100GbE ports 10 I/O module slots maximum depending on model
Fläkt
Two field replaceable system fan trays
Vikt (imperial)
53,6 kg (118.2 lbs)
Minne och processor
CPU Management Module: Quad-core Arm Cortex A72 at 1.8 GHz Line Cards: Dual-core Arm Cortex A72 at 1.8 GHz (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: Quad-core Arm Cortex A72 at 1.8 GHz (R0X38C‐R0X45C, S0E48A, S1T83A) Memory and flash Management Module: 16 GB DDR4 ECC memory: 32 GB eMMC Flash memory Line Cards: 4 GB DDR4 memory (R0X38A‐R0X45A and R0X38B‐R0X40B) Line Cards: 8 GB DDR4 memory (R0X38C‐R0X45C, S0E48A, S1T83A)
Prestandahantering
1 x RJ‐45 console port 1 x USB‐C console port 1 x OOBM port 1 x USB Type-A host port HPE Aruba Networking Management Software (AirWave) HPE Aruba Networking Central HPE Aruba Networking Switch Multi-Edit Software HPE Aruba Networking CX Mobile App Command-line interface SNMP v2c/v3 RMON
Latens
1G: 5.32 μSec 10G: 1.48 μSec 25G: 2.78 μSec 40G: 1.31 μSec 100G: 1.42 μSec
Miljökrav
Temperatur vid drift
0 - 45 ° C
Vikt & dimension
Höjd
448,5 mm
Bredd
528,8 mm
Djup
442,6 mm
Vikt
53,5 kg
|
