Produktblad
Anslutningar
Typ av grundläggande RJ-45 Ethernet-portar
Fast Ethernet (10/100)
Antal grundläggande RJ-45 Ethernet-portar
8
Design
Produktens färg
Silver
Prestanda
Inbyggd processor
Processorfrekvens
1200 MHz
Internminne
4096 MB
Minnestyp
DDR3-SDRAM
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Vikt (imperial)
0,93 kg (2.05 lbs)
Minne och processor
Depend on the model: Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Arm 11 at 450 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1; Packet buffer size: 13.5 MB internal Arm 11 at 550 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Freescale P2020 dual core at 1.2 GHz, 16 MB flash, 1 GB SD Card, 4 GB DDR3 SODIMM.
Prestandahantering
HPE Aruba Networking Management Software HPE Aruba Networking Central HPE Intelligent Management Center Basic Software Platform (IMC) Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) Out-of-band management (serial RS-232C or micro USB) SNMP manager
Dimension (B x D x H) (imperial)
261,6 x 206,5 x 44,5 mm (10.3 x 8.13 x 1.75")
Externa anslutningar
Up to (12) open module slots, maximum. Supports a maximum of (288) 10/100/1000 ports or (288) SFP ports or (96) SFP+ ports or (96) HPE Smart Rate Multi-Gigabit or (24) 40 GbE ports, or a combination. Pre-configured models, some with PoE/PoE+, can support 10/100/1000 GbE, 10 GbE and 40GbE.
Latens
1000 Mb Latency: < 2.8 μs; 10 Gbps Latency: < 1.8 μs; 40 Gbps Latency: < 1.5 μs
Vikt & dimension
Vikt
930 g
Höjd
44,5 mm
Bredd
261,6 mm
Djup
206,5 mm
Logistikdata
Harmonized System (HS)-kod
85176990
|
