Produktblad
Management features
Switch typ
hanterad
Data transmission
Latens (1 Gbps)
2,9 ps
Latens (10 Gbps)
2 ps
Genomströmning
1142,8 Mpps
Switch kapacitet
1920 Gbit/s
Design
Produktens färg
Grå
Prestanda
Inbyggd processor
Processorfrekvens
1200 MHz
Internminne
4096 MB
Processor
QorIQ P2020
Flashminne
16 MB
Minnestyp
DDR3-SDRAM
Strömtillförsel
AC-inspänning
200 - 240 V
Strömförsörjning ingår
Notering för strömförsörjning
4 power supply slots 2 minimum power supplies required (ordered separately)
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Övrigt
Vikt (imperial)
17,3 kg (38.1 lbs)
Minne och processor
Depend on the model: Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Arm 11 at 450 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1; Packet buffer size: 13.5 MB internal Arm 11 at 550 MHz; Packet buffer size: 18 MB internal. Dual Arm Cortex A9 at 1 GHz; Packet buffer size: 13.5 MB internal Freescale P2020 dual core at 1.2 GHz, 16 MB flash, 1 GB SD Card, 4 GB DDR3 SODIMM.
Prestandahantering
HPE Aruba Networking Management Software HPE Aruba Networking Central HPE Intelligent Management Center Basic Software Platform (IMC) Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) Out-of-band management (serial RS-232C or micro USB) SNMP manager
Dimension (B x D x H) (imperial)
444,5 x 450,9 x 307,3 mm (17.5 x 17.8 x 12.1")
Externa anslutningar
12 open module slots Supports a maximum of 288 autosensing 10/100/1000 ports or 288 SFP ports or 96 SFP+ ports or 96 HPE Smart Rate Multi-Gigabit or 24 40 GbE ports, or a combination.
Latens
1000 Mb Latency: < 2.8 μs; 10 Gbps Latency: < 1.8 μs; 40 Gbps Latency: < 1.5 μs
Miljökrav
Värmeavgivning
4900 BTU/h
Vikt & dimension
Vikt
17,3 kg
Höjd
307,3 mm
Bredd
444,5 mm
Djup
450,9 mm
|
